use and maintenance Scarabeo 50 - Scarabeo 100
KEY TO WIRING DIAGRAM - Scarabeo
1) Multiple connectors
2) Instrument panel
3) Oil level warning light
4) Dashboard bulbs
5) High beam warning light
6) Direction indicator warning light
7) Fuel level tool
8) Check diode
9) Key-operated switch
10) Warning horn
11) Left dimmer switch
12) Right dimmer switch
13) Rear left direction indicator
14) Rear parking light/stoplight bulb
15) Tail light
16) Rear right direction indicator
17) Fuel sensor
18) Oil level switch
19) Front stoplight switch
20) Rear stoplight switch
21) Start relay
22) Starter
23) Fuses
24) Battery
25) Voltage regulator
26) Pick-up
27) Generator
28) Spark plug
29) Transducer
30) Automatic cold start
31) Front right direction indicator
32) Low beam /high beam bulb
33) Front left direction indicator
34) -
35) -
36) -
37) -
CABLE COLOUR
Ar Orange
Az Light blue
B Blue
Bi White
G Yellow
Gr Grey
M Brown
N Black
R Red
V Green
Vi Violet
Ro Pink
50 2T50 2T
