use and maintenance Scarabeo 50 - Scarabeo 100
KEY TO WIRING DIAGRAM - SCARABEO
1) Generator
2) Transducer
3) Spark plug
4) -
5) Voltage regulator
6) Battery
7) Starter
8) Start relay
9) Front stoplight switch
10) Rear stoplight switch
11) -
12) -
13) Fuel sensor
14) Rear right direction indicator
15) Rear parking light/stoplight bulb
16) Rear left direction indicator
17) Right dimmer switch
18) Left dimmer switch
19) Key-operated switch
20) -
21) -
22) -
23) Instrument panel
24) -
25) High beam warning light
26) Dashboard bulbs
27) Fuel level tool
28) -
29) High beam warning light
30) Direction indicator warning light
31) Front right direction indicator
32) Front left direction indicator
33) -
34) Low/high beam bulb (35/35W)
35) Warning horn
36) Pick-up
37) Fuse
38) Multiple connectors
39) -
40) Automatic cold start
CABLE COLOUR
Ar Orange
Az Light blue
B Blue
Bi White
G Yellow
Gr Grey
M Brown
N Black
R Red
V Green
Vi Violet
504T
10 0 4T
