A.4 FMC-HPC connector
The MPS3 board provides a 400‑way Samtec SEARAY connector to support the FPGA Mezzanine Card
standard, high pin count variant, FMC‑HPC.
The following figure shows the FMC‑HPC connector, J9.
1 40
400361
Figure A-9 FMC-HPC connector
The pin mapping of the FMC‑HPC connector conforms to the FPGA Mezzanine Card (FMC) Standard
ANSI/VITA 57.1. See http://www.vita.com/ for the pin mapping of the FMC‑HPC connector.
Arm supplies two spreadsheets that describe the FPGA-FMC connectivity on the MPS3 board. See
FPGA-FMC pin connectivity on page 2-46 for information on how to download the spreadsheets.
Related information
2.17 FMC-HPC interface on page 2-46
1.3 Location of components on the MPS3 board on page 1-15
A Signal descriptions
A.4 FMC-HPC connector
100765_0000_04_en Copyright © 2017–2020 Arm Limited or its affiliates. All rights
reserved.
Appx-A-82
Non-Confidential
