A.5 FMC configuration connector
The MPS3 board provides a custom 14‑pin connector to enable configuration of Arm FMC boards.
The FMC configuration connector is reserved for Arm FMC boards only.
The following figure shows the FMC‑HPC configuration connector, J61.
1
13
2
14
Figure A-10 FMC-HPC configuration connector
Related information
2.17 FMC-HPC interface on page 2-46
1.3 Location of components on the MPS3 board on page 1-15
A Signal descriptions
A.5 FMC configuration connector
100765_0000_04_en Copyright © 2017–2020 Arm Limited or its affiliates. All rights
reserved.
Appx-A-83
Non-Confidential
