A.6 Combined Ethernet and dual USB-A connector
The MPS3 board provides a combined Ethernet and dual USB-A connector that connects to the Ethernet
10/100 controller and to the USB 2.0 controller.
The following figure shows the combined Ethernet and dual USB-A connector, J2.
USB 2.0
port 1
USB 2.0
port 2
Ethernet
10/100
Figure A-11 Combined Ethernet and dual USB-A connector
Related information
2.8 USB 2.0 and Ethernet static memory interface on page 2-35
1.3 Location of components on the MPS3 board on page 1-15
A Signal descriptions
A.6 Combined Ethernet and dual USB-A connector
