Asus P8P67 WS Revolution User Manual

4-8 Chapter 4: Software support
• Set the CPU Ratio Setting item in BIOS to [Auto] before using the CPU
Ratio function in TurboV. Refer to Chapter 3 of your motherboard user
manual for details.
• The CPU Ratio bars show the status of the CPU cores, which vary with
your CPU model.

bar
4. Drag the adjustment bar upwards or downwards to the desired value.
Auto Tuning
ASUS TurboV EVO includes two auto tuning modes, providing the most flexible
auto-tuning options.
• The overclocking result varies with the CPU model and the system
configuration.
• To prevent overheating from damaging the motherboard, a better thermal
environment is strongly recommended.
• Fast Tuning: fast CPU overclocking
• Extreme Tuning: extreme overclocking for CPU and memory
Using Fast Tuning
1. Click the Auto Tuning tab and
then click Fast.
2. Read through the warning
messages and click OK to
start auto-overclocking.

Asus P8P67 WS Revolution Specifications

General

Chipset	Intel P67
CPU Socket	LGA 1155
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
RAID Support	RAID 0, 1, 5, 10
Memory Support	4 x DIMM, Max. 32GB
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz
Storage	4 x SATA 3Gb/s
USB Ports	12 x USB 2.0 (6 at back panel, 6 by internal headers), 2 x USB 3.0 (at back panel)
Networking	Dual Gigabit LAN
