Asus P8P67 WS Revolution User Manual

4-26 Chapter 4: Software support
4.5.3 Installing the RAID driver during Windows
®
OS
installation
To install the RAID driver in Windows
®
XP:
1. During the OS installation, the system prompts you to press the F6 key to
install third-party SCSI or RAID driver.
2. Press <F6>, and then insert the floppy disk with RAID driver into the USB floppy
disk drive.
3. When prompted to select the SCSI adapter to install, select the RAID driver
for the corresponding OS version.
4. Follow the succeeding screen instructions to complete the installation.
To install the RAID driver for Windows
®
Vista or later OS:
1. During the OS installation, click Load Driver to allow you to select the
installation media containing the RAID driver.
2. Insert the USB flash drive with RAID driver into the USB port or the support
DVD into the optical drive, and then click Browse.
3. Click the name of the device you’ve inserted, go to Drivers > RAID, and then
select the RAID driver for the corresponding OS version. Click OK.
4. Follow the succeeding screen instructions to complete the installation.
Before loading the RAID driver from a USB flash drive, you have to use another
computer to copy the RAID driver from the support DVD to the USB flash drive.

Asus P8P67 WS Revolution Specifications

General

Chipset	Intel P67
CPU Socket	LGA 1155
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
RAID Support	RAID 0, 1, 5, 10
Memory Support	4 x DIMM, Max. 32GB
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz
Storage	4 x SATA 3Gb/s
USB Ports	12 x USB 2.0 (6 at back panel, 6 by internal headers), 2 x USB 3.0 (at back panel)
Networking	Dual Gigabit LAN
