AI Suite II
One-stop Access to Innovative ASUS Features
With its fast user-friendly interface, ASUS AI Suite II consolidates all exclusive
ASUS features and allows you to supervise overclocking, energy management
and fan speed control, voltage and sensor readings, even interact with your mobile
via Bluetooth technology. All in one place so you enjoy different functions without
switching utilities back and forth.
ASUS Quiet Thermal Solution
ASUS Quiet Thermal solution makes system more stable and enhances the
overclocking capability.
ASUS Fanless Design—Heat-pipe solution
The Heat Pipe design effectively directs the heat generated by the vCore
area to the heatsink near the back IO ports, where it can be carried away by
existing airflow from CPU fan. The purpose of the innovative heat pipe design
on this motherboard is that the groundbreaking fanless design does not have
lifetime problems as a chipset fan does. The Heat Pipe design is the most
reliable fanless thermal solution to date.
DO NOT uninstall the heat-pipe by yourself. Doing so may bend the tubing and
affect the heat dissipation performance.
Fan Xpert
Active Quiet & Cool
ASUS Fan Xpert intelligently allows users to adjust both the CPU and chassis
fan speed according to different ambient temperature, which is caused
by different climate conditions in different geographic regions and system
loading. Built-in variety of useful profiles offer flexible controls of fan speed to
achieve a quiet and cool environment.
ASUS EZ DIY
ASUS EZ DIY feature collection provides you easy ways to install computer
components, update the BIOS or back up your favorite settings.
EFI BIOS(EZ Mode)
Flexible, Easy BIOS Interface
ASUS brand new EFI BIOS offers a user-friendly interface that goes beyond
traditional keyboard BIOS input to enable more flexible and convenient
mouse controls. Users can easily navigate the EFI BIOS with the same
smoothness as their favorite operating system, while the exclusive EZ Mode
displays frequently-accessed setup info with no additional steps needed to
enter Advanced Mode for more settings.

Asus P8P67 WS Revolution Specifications

General

Chipset	Intel P67
CPU Socket	LGA 1155
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
RAID Support	RAID 0, 1, 5, 10
Memory Support	4 x DIMM, Max. 32GB
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz
Storage	4 x SATA 3Gb/s
USB Ports	12 x USB 2.0 (6 at back panel, 6 by internal headers), 2 x USB 3.0 (at back panel)
Networking	Dual Gigabit LAN
