Asus P8P67 WS Revolution User Manual

2.1 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
• Unplug the power cord from the wall socket before touching any
component.
• Before handling components, use a grounded wrist strap or touch a safely
grounded object or a metal object, such as the power supply case, to avoid
damaging them due to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic
pad or in the bag that came with the component.
• Before you install or remove any component, ensure that the ATX power
supply is switched off or the power cord is detached from the power
supply. Failure to do so may cause severe damage to the motherboard,
peripherals, or components.
ASUS P8P67 WS Revolution 2-1

Asus P8P67 WS Revolution Specifications

General

Chipset	Intel P67
CPU Socket	LGA 1155
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
RAID Support	RAID 0, 1, 5, 10
Memory Support	4 x DIMM, Max. 32GB
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz
Storage	4 x SATA 3Gb/s
USB Ports	12 x USB 2.0 (6 at back panel, 6 by internal headers), 2 x USB 3.0 (at back panel)
Networking	Dual Gigabit LAN

Summary

Chapter 1: Product Introduction

Welcome!

Welcomes the user and introduces the motherboard.

Package Contents

Lists all items included in the motherboard package.

Special Features Overview

Highlights key technologies and features of the motherboard.

Chapter 2: Hardware Information

Before You Proceed

Provides essential precautions before installing hardware components.

Motherboard Overview and Components

Details the motherboard's layout, key components like CPU, memory, slots, and connectors.

Building Your Computer System

Guides on the physical installation of PC components onto the motherboard.

Chapter 3: BIOS Setup

BIOS Setup Program and Management

Covers entering BIOS, navigation, and updating procedures.

Ai Tweaker Menu

Configuration options for CPU and memory overclocking.

Advanced System Configuration

Configure CPU, devices, monitor status, and manage boot options.

Chapter 4: Software Support

System Setup and Support Resources

Guides for OS installation and information on support DVD contents.

ASUS Software Utilities

Explains ASUS utilities like AI Suite, DIGI+ VRM, TurboV EVO, EPU.

RAID Configurations and Setup

Information on SATA RAID solutions and how to create driver disks.

Chapter 5: Multiple GPU Technology Support

ATI CrossFireX Technology

Instructions for installing and enabling ATI CrossFireX graphics cards.

NVIDIA SLI Technology

Guides on installing and enabling NVIDIA SLI graphics cards.

NVIDIA CUDA Technology

Information on installing NVIDIA CUDA-ready graphics cards.
