3.4 Ai Tweaker menu
The Ai Tweaker menu items allow you to configure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect
field values can cause the system to malfunction.
The configuration options for this section vary depending on the CPU and DIMM
model you installed on the motherboard.
Scroll down to display the following items:
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
[X.M.P.] When XMP is enabled BLCK
frequency, CPU ratio and memory
parameters will be auto optimized.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
EFI BIOS Utility - Advanced Mode
Target CPU Turbo-Mode Speed : 3100MHZ
Target DRAM Speed : 1066MHz
Ai Overclock Tuner Auto
Turbo Ratio Auto
Memory Frequency Auto
EPU Power Saving Mode Disabled
> OC Tuner
> DRAM Timing Control
> CPU Power Management
DIGI+ VRM
Load-Line Calibration Auto
VRM Frequency Auto
VRM Spread Spectrum Disabled
Phase Control Standard
Duty Control T.Probe
CPU Current Capability 100%
CPU Voltage 1.208V Offset Mode
Offset Mode Sign +
CPU Offset Voltage Auto
DRAM Voltage 1.500V Auto
VCCSA Voltage 0.850V Auto
VCCIO Voltage 1.050V Auto
CPU PLL Voltage 1.800V Auto
PCH Voltage 1.050V Auto
DRAM DATA REF Voltage on CHA Auto
DRAM CTRL REF Voltage on CHA Auto
