Asus P8P67 WS Revolution User Manual

ASUS P8P67 WS Revolution
1-1
1.1 Welcome!
Thank you for buying an ASUS P8P67 WS Revolution motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.
If any of the above items is damaged or missing, contact your retailer.
1.2 Package contents
Check your motherboard package for the following items.
Motherboard ASUS P8P67 WS Revolution
I/O modules 1 x 2-port USB 2.0 module and 1-port eSATA module
Cables 4 x Serial ATA 6.0 Gb/s signal cables
2 x Serial ATA 3.0 Gb/s power cables
4 x Serial ATA 3.0 Gb/s cables
1 x COM port cable
Accessories 1 x ASUS Q-Shield (I/O shield)
1 x ASUS 2-in-1 Q-Connector Kit (Retail version only)
1 x G.P. Diagnosis Card (Retail version only)
1 x ASUS SLI bridge connector
1 x ASUS 3-Way SLI bridge card
Application DVD ASUS motherboard support DVD
Documentation User guide

Asus P8P67 WS Revolution Specifications

General

Chipset	Intel P67
CPU Socket	LGA 1155
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
RAID Support	RAID 0, 1, 5, 10
Memory Support	4 x DIMM, Max. 32GB
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz
Storage	4 x SATA 3Gb/s
USB Ports	12 x USB 2.0 (6 at back panel, 6 by internal headers), 2 x USB 3.0 (at back panel)
Networking	Dual Gigabit LAN
