Asus P8P67 WS Revolution User Manual

ASUS P8P67 WS Revolution 4-27
 
Due to OS limitation, Windows
®
XP may not recognize the USB floppy disk drive
when you install the RAID driver from a floppy disk during the OS installation.
To solve this issue, add the USB floppy disk drive’s Vendor ID (VID) and Product
ID (PID) to the floppy disk containing the RAID driver. Refer to the steps below:
1. Using another computer, plug the USB floppy disk drive, and insert the floppy
disk containing the RAID driver.
2. Right-click My Computer on
the Windows
®
desktop or start
menu, and then select Manage
from the pop-up window.
3. Select Device Manager. From the
Universal Serial Bus controllers,
right-click xxxxxx USB Floppy,
and then select Properties from
the pop-up window.
The name of the USB floppy
disk drive varies with different
vendors.
or
4. Click Details tab. The Vendor ID
(VID) and Product ID (PID) are
displayed.
5. Browse the contents of the RAID driver disk to locate the file txtsetup.oem.
6. Double-click the file. A window
appears, allowing you to select the
program for opening the oem file.

Asus P8P67 WS Revolution Specifications

General

Chipset	Intel P67
CPU Socket	LGA 1155
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
RAID Support	RAID 0, 1, 5, 10
Memory Support	4 x DIMM, Max. 32GB
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz
Storage	4 x SATA 3Gb/s
USB Ports	12 x USB 2.0 (6 at back panel, 6 by internal headers), 2 x USB 3.0 (at back panel)
Networking	Dual Gigabit LAN
