Atlas Copco HiLight H4 Kd ESF User Manual

- 71 -
10 Technical specifications of the light tower
10.1 Technical specifications of the engine/alternator/unit
50 Hz (230V - 1ph)
Reference conditions 1) Rated frequency 50 Hz
Rated speed 1500 rpm
Generator service duty PRP
Absolute air inlet pressure 1 bar(a)
Relative air humidity 30%
Air inlet temperature 25°C
Limitations 2) Maximum ambient temperature 50°C
Altitude capability 3500 m
Maximum relative air humidity 85%
Minimum starting temperature -5°C
Minimum starting temperature, with coldstart equipment (optional - to be developed) -25°C
Performance data 2) 3) 4) 5) Rated active power (PRP) 1 ph 4.9 kW
Rated power factor (lagging) 1ph 1 cos φ
Rated apparent power (PRP) 1ph 4.9 kVA
Rated voltage 1ph line to line voltage 230 V
Rated current 1ph 21.3 A
Performance class (acc. ISO 8528-5:1993) G2
Single step load acceptance (0-PRP) 100%
4.9 kW
Frequency droop (lower than % /isochronous) isochronous
Fuel consumption at no load (0%) 0.86 kg/h
Fuel consumption at 50% load 1.11 kg/h
Fuel consumption at 75% load 1.30 kg/h
Fuel consumption at full load (100%) 1.88 kg/h
Specific fuel consumption 0.324 kg/kWh
Fuel autonomy at full load (100%) with standard tank 55 h
Max. oil consumption at full load 0.02 l/h
00_00_HiLight H4_EN.book Page 71 Monday, April 18, 2016 2:10 PM
