- 75 -
10.2 Critical bolt connections
Applications
Screw / Bolt / Nut
Type Material Torque (Nm)
Lifting beam to frame M12 8.8 85
Horizontal lifting beam to vertical lifting beam M12 8.8 85
Coupling housing alternator to flywheel housing engine 3/8" UNC 8.8 35
Rotor disk alternator to flywheel engine 5/16" UNC 8.8 21
Engine to engine support M10 8.8 50
Engine support to vibration damper engine M10 8.8 50
Vibration damper engine to frame M10 8.8 50
Alternator support to vibration damper alternator M10 8.8 50
Rotatory base to base frame M14 8.8 135
Floodlight support to top of the mast M12 8.8 85
Floodlight support to floodlight M10 8.8 50
Wheel to axle M12 8.8 120
Axle to frame M12 8.8 85
Towbar to frame M12 8.8 85
Towing eye to towbar M12 8.8 85
Standard torques
M4 8.8 3
M5 8.8 6
M6 8.8 10
M8 8.8 25
M10 8.8 50
M12 8.8 85
M14 8.8 135
