2 Specifications
© Copyright Reserved Autonics Co., Ltd. 19
2 Specifications
Series
CXS
CXM
Model
CX6S-1P
□□
CX6S-2P
□□
CX6M-1P
□□
CX6M-2P
□□
Display digits 6-digit
Display method
7-segment (1st, 2nd digits of counting value display: white,
setting value display: green) LCD method,
11-segment (the other digits of counting value display: white) LCD method,
Operation display part: yellow LCD method
Character
size
(W×H)
Counting value
4.1×10.1mm 6.2×15.2mm
Setting value
3.3×8.1mm 5×12.3mm
Power
supply
AC voltage 100-240VACЖ 50/60Hz
AC/DC voltage 24VACЖ 50/60Hz, 24-48VDCЗ
Permissible voltage range 90 to 110% of rated voltage
Power
consump
tion
AC
voltage
CX6□-□□
Max. 6.4VA Max. 6.7VA Max. 7.1VA Max. 7.5VA
CX6□-□□F
Max. 4.2VA Max. 4.9VA Max. 4.7VA Max. 5.4VA
AC/DC
voltage
CX6□-□□
AC: max. 5.5VA
DC: max. 3.5W
AC: max. 5.6VA
DC: max. 3.6W
AC: max. 6.2VA
DC: max. 4W
AC: max. 6.3VA
DC: max. 4.1W
CX6□-□□F
AC: max. 3.6VA
DC: max. 2.5W
AC: max. 4.0VA
DC: max. 2.8W
AC: max. 3.9VA
DC: max. 2.9W
AC: max. 4.5VA
DC: max. 3.3W
Counter
Max.
INA/INB
counting
speed
CX6□-□□
Selectable among 1cps/30cps/300cps/1kcps/5kcps
CX6□-□□F
20cps
Counting range -99999 to 999999
Scale Decimal point up to fifth digit
Min.
signal
width
CX6□-□□
RESET, TOTAL RESET signal: selectable among 1ms/20ms
CX6□-□□F
RESET signal: 25ms
Timer
Time range
999.999s, 9999.99s, 99999.9s, 999999s, 99m59.99s, 999m59.9s, 9999m59s,
99999.9m, 999999m, 99h59m59s, 9999h59m, 99999.9h
Operation mode Up, Down
Min.
signal
width
CX6□-□□
INA, INHIBIT, RESET, TOTAL RESET signal: selectable among 1ms/20ms
CX6□-□□F
INA, INH, RESET signal: 25ms
Repeat error
[CX6□-□□] – In case of power ON start: max. ±0.01% ±0.05s
In case of signal ON start: max. ±0.01% ±0.03s
[CX6□-□□F] - In case of power ON start: max. ±0.01% ±0.08s
In case of signal ON start: max. ±0.01% ±0.06s
SET error
Voltage error
Temperature error
