Autonics CX Series User Manual

5 Counter mode
38 © Copyright Reserved Autonics Co., Ltd.
5.1.4 Checking SV of TOTAL counter
 Press the key in RUN mode and it operates SET2 → SET1 → TOTAL Counter in
order.
 At TOTAL counter operation, the counting value display component displays the current
value and the setting value display component displays TOTAL counter counting value.
 When TOTAL counter counting value is over 999999, it counts from 0 again.
5.1.5 Function setting check mode
(only for free voltage input model (CX6□-□□F))
 Hold the key over 1 sec to enter function setting check mode in RUN mode.
 When checking the saved parameters, press the , key to check next item.
 Hold the key over 1 sec at function setting check mode and it returns to RUN mode.
 At function setting check mode, the counting value display component displays the
parameters and the setting value display component displays the SV of the parameters.
5.1.6 Switching display of the setting value display component
In case of 2-stage setting model(CX6□-2P□□), whenever pressing the key, each SET2,
SET1, TOTAL COUNTER
※
1
value displays consecutively.
※1: This is for the voltage input(PNP)/no-voltage input(NPN) selectable model (CX6□-□□).
5.1.7 Display HOLD output mode for counter
 It displays the over value of prescale value.
 When SV is n multiplied by prescale value and the display value after HOLD output mode
and SV are different, the prescale value is not the 1/n time of SV.
5.1.8 RESET
 In RUN mode, function setting mode, press the key to reset the current value and
the output turns OFF.
 At TOTAL counter display mode
※1
, press the key to reset TOTAL counter counting
value and the current counting value.
※1: This is for the voltage input(PNP)/no-voltage input(NPN) selectable model (CX6□-□□).
TOTAL counter display mode is only when counter operation.
