Autonics CX Series User Manual

6 Timer mode
64 © Copyright Reserved Autonics Co., Ltd.
※1: This is for the voltage input(PNP)/no-voltage input(NPN) selectable model (CX6□-□□).
※2: INt2 mode is available only for 2-stage setting model (CX6□-2P□□).
6.2.4 Time range
Set timer time range.
※Set time setting range of OnRNG, OFfRNG, tRNG.
6.2.5 OUT2 (OUT) output time
Set one-shot output time of OUT2 or OUT. (unit: sec)
※Setting range: 00.01s to 99.99s, HOLD
 key: Moves the setting digit of output time value.
 key: Changes the flashing digit value.
※When number of tens digit flashes, press the key once and HOLDis displayed.
(1) When changing output time setting as 500m
 Press the key to move the flashing digit at the setting value display component.
 Press the keys to set as 5 of the 2nd digit.
 Press the key to save SV and moves to next parameter.
