Panel Overview
Operator's Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-OPERATE/FGB Rev.G, 2016-02-19,
Autronica Fire and Security AS
Page 24
Button Designation Access
Level
Mute Panel
(black)
Used to mute the panel, i.e. silence the internal
buzzer. Timeout.
(Information Loop Panel: The Mute Panel button is
named Silence Buzzer. The Backlight Brightness can
be toggled between high and low by holding the
Silence Buzzer button for 5 seconds until audible
beep (access level 1).
1
Next Window
(red)
Used to step to the next condition window (only
windows with active information are displayed). After
all windows have been shown, the first window is
displayed. When a timeout on no operation has been
ended, the highest prioritized window is displayed.
1
Lamp Test
(green)
Used for testing the LED indicators. All indicators are
lit for 5 seconds, and the LCD (display) will show a
pattern to verify all pixels (will turn all white, then all
black).
1
More Events
(black)
Used to scroll pages of information related to the
selected condition window, if there are more events
than the display can show.
1
