Operation Mode
Operator's Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-OPERATE/FGB Rev.G, 2016-02-19,
Autronica Fire and Security AS
Page 29
3.6 Alarm Presentation with Zonal and Point Indication
(default)
By default alarms are presented with both zonal indication and point
indication.
“FIRE ALARMS” is highlighted in the upper left corner of the display.
In the example below an optical smoke detector in the “Main building
Show room gr. floor” (1 zone) issues an alarm signal.
A manual call point in the reception area is activated. A total of 2
alarms from 2 different zones are now shown in the display.
The heat detector in the “Main building Show room gr. floor” issues an
alarm signal. A total of 3 alarms from 2 zones are shown in the
display.
FIRE ALARMS
19:23
Total: 1
1 Main building Show room gr. floor
A1021 Smoke
Latest zone in alarm
Main building Show room gr. floor
Zones: 1
FIRE ALARMS
19:23
Total: 1
1 Main building Show room gr. floor
A1021 Smoke
Latest zone in alarm
Main building Show room gr. floor
Zones: 1
FIRE ALARMS
19:24
Total: 2
2 Main building Reception area
A1019 Manual callpoint
Latest zone in alarm
Main building Reception area
Zones: 2
1 Main building Show room gr. floor
A1021 Smoke
FIRE ALARMS
19:24
Total: 2
2 Main building Reception area
A1019 Manual callpoint
Latest zone in alarm
Main building Reception area
Zones: 2
1 Main building Show room gr. floor
A1021 Smoke
FIRE ALARMS
19:24
Total: 3
2 Main building Reception area
A1019 Manual callpoint
Latest zone in alarm
Main building Show room gr. floor
Zones: 2
1 Main building Show room gr. floor
A1021 Smoke
3 Main building Show room gr. floor
A1020 Heat
FIRE ALARMS
19:24
Total: 3
2 Main building Reception area
A1019 Manual callpoint
Latest zone in alarm
Main building Show room gr. floor
Zones: 2
1 Main building Show room gr. floor
A1021 Smoke
3 Main building Show room gr. floor
A1020 Heat
