Axon Fleet 2 Installation Manual
Axon Enterprise, Inc. Page 23 of 39
Axon Fleet Power Unit
The choice of which location is based on the availability of wires. Installer should be able to
access the car wires outlined below. It is the installers discretion as to location chosen.
1. Active Power
2. Ground
3. Ignition/accessory
The power unit should be located so that each 18-foot (5.5 m) wiring harness (SKU 71085)
can reach their respective camera. The wiring harness should be trimmed as needed for
installations that do not require the full length of the harness.
Important: While it is recommended to shorten the18-foot wiring harness DO NOT extend
the harness or splice the cables in any manner. Service loops or “wadding” of this cable must
also be avoided.
Axon Fleet Cameras and Mounts
The Axon Fleet 2 cameras draw power from their associated Axon Fleet power unit, and
therefore the front camera and rear camera controller must be connected to a power unit
using the 18-foot (5.5 m) wiring harness (SKU 71085). Do not mount any of the hardware on
the exterior of the vehicle or inside the engine compartment.
The Axon Fleet 2 system front and rear cameras have Ingress Protection (IP) ratings of IP53
and IP54, respectively. However, the entire Axon Fleet 2 system does not have an IP rating
and should not be considered waterproof.
Front Camera and Mount
With the Axon Fleet 2 front camera properly secured to the Axon Fleet 2 mount and without
permanently affixing the mount, determine the appropriate location to affix the mount upon
the interior of the windshield.
The swivel ball joint on the camera is inserted directly up into the mount. Tighten the
thumbscrew to hold the camera in place.
Do not install the camera anywhere that will interfere with airbag deployment or adversely
obstruct the driver’s view.
It is recommended that the front camera be mounted on the center part of the windshield,
approximately 1-1/2″ (3.8 cm) from the headliner.
