DSP features and controls are described in the following table.
The DSP features that can be applied to a channel, accessible through the DSP Features
me
nu, are described in the following table.
Note: The DSP page (including the mixing board and other DSP pages) can only be
us
ed by one browser session at a time. If another session is already connected and
using this DSP page, the mixing board displayed will be disabled.
Note: If two output connectors are configured for Bridge mode (A/B), the output chan-
nel that corresponds to the second connector (B) will not appear on the mixing board
in
terface.
Table 8. DSP Page
Save Settings to Server Backs up the DSP settings to the server. If this device is
la
ter replaced or reset to factory defaults, these DSP set-
tings can be restored when the new device is “swapped”
f
o
r the old on the Nyquist server.
Note: This button appears on each DSP feature page.
Mute Silences the audio for the selected channel.
DSP Features button Presents a menu of DSP features that can be applied to the
c
o
rresponding channel.
Level Slider Adjusts the channel volume level in 1–dB increments.
NET-IN LED Illuminates when a signal is being received from the Net-
work stream input.
LINE-IN LED Illuminates when a signal is being received from the ana-
log Line input.
Clip LED Illuminates when a signal has exceeded the maximum
th
reshold, indicating that the signal is “clipping.”
IN VU meter Indicates the strength of the input signal.
OUT VU meter Indicates the strength of the output signal.
Pink Noise When set to ON, a pink noise signal will be sent to the out-
put channel.
Phase Invert When set to ON, the signal for this channel is inverted,
u
s
ually to prevent two similar but out-of-phase signals
from canceling each other out.
