37
Tip: The Presets feature contains predefined Peak Limiter settings for a number of specific speakers.
To adjust the Peak Limiter settings for a channel:
1 On the appliance Web UI’s main page, select DSP.
2 Select the Menu button for the channel.
3 From the drop-down menu, select Peak Limiter.
4 Make desired adjustments using the controls described in Table 16, “Peak Limiter Set-
tings,” on page 38.
5 Select Enable to apply the settings to the selected channel.
Figure 17. Peak Limiter Settings
Note: If you want to return to the factory settings, select the Reset icon that appears in
the right corner.
