Control Panels B93x keypad operation overview | en
43
Bosch Security Systems B.V. 2019.06 | 07 | F.01U.307.371
12.3 Status indicators overview
The Status indicators on the keypad provide a quick visual reference for
you to see how your system is operating.
Ready to arm. The green checkmark indicates whether the
system is ready to turn on (arm).
– ON Steady. All points are normal and the system is ready to
turn on.
– OFF. One or more points are faulted, and the system is not
ready to turn on.
On (armed). The red lock indicates whether the system is on
(armed).
– ON Steady. All areas are on with no alarms.
– Flashing. All areas are armed, and there is an active alarm.
– OFF. One or more areas are off.
Trouble. The yellow caution lights when a trouble condition
exists.
– ON Steady. There is a system, device, or point trouble.
– OFF. There are no system, device, or point troubles.
GAS. The blue GAS indicates a gas alarm.
