c
ERROR
CODES)
1)
Some problems
will
be indicated by an error code, others
will
not. Refer
to
both sections.
2)
A defective circuit board (main circuit board and others) can also
cause
problems.
If
the
problem cannot
be corrected, replace
the
circuit board.
3)
Be
sure
to
turn
the
power
off
before checking continuity.
4) A special
1/0
diagnostics
PROM
is
available
to
check
the
operation
of
the
operation box switches,
the
treadle, and
the
start switch.
1.
Problems indicated by an error code
* Refer
to
the
following
tables
to
rectify
the
problem when an error code appears.
<D
<
EOO
>
or
<
E-0-00
> appears when carriage feed
is
moving.
Cause
Check Solution
Page
1.
Emergency
stop
switch
<Normal
operation>
See
reset procedure and reset.
33
pressed
during
carriage feed
(lnst-
operation.
ruction
manual)
2.
Emergency
stop
signal
Emergency
stop
switch
Replace emergency stop switch.
received
during
carriage
continuity.
feed operation.
3.
Defective
emergency
stop
Replace main circuit board.
88
switch circuit
®
<E10>
or
<E-1-00>
appears
when
power
is
turned on.
1.
Start
switch
pressed
or
Remove start switch connector;
Replace start switch.
shorted.
if
error code disappears, check
start switch continuity.
3.
Defective start switch circuit
Replace main circuit board.
88
-113-
