Appendix ——————————————————————————————————————————————————————————
—
176
■ Removing the cap frame
After embroidering is finished, remove the cap
frame, and then remove the cap.
1
Remove the cap frame from the cap frame
driver.
Press both of the two holders at the base of the
cap frame with both thumbs, and then pull off
the embroidery frame, as shown in the
illustration.
1 Holder
As shown in the illustration, turn the
embroidering position to the side when
removing the cap frame so the brim of the cap
does not hit the embroidery machine.
• Be careful that the cap frame does not hit
any nearby parts, such as the presser foot.
2
Release the snap lock on the cap frame, and
then remove the cap.
Installing the embroidery
frame holder
After embroidering using the cap embroidery frame
is finished, remove the needle plate spacer and cap
frame driver, and then re-attach the embroidery
frame holder.
1
Remove the needle plate spacer.
1 Needle plate spacer
2
Loosen the two lower thumb screws.
1 Thumb screws
3
Remove the two upper thumb screws
1 Thumb screws
1
1
2
1
Sapphire.book Page 176 Friday, August 1, 2003 9:12 AM
