Components Guide
D.EFFECTS button ( 71) /
/ (play/pause) button ( 39)
FINALIZE button ( 98)
Memory card slot ( 30)
LIGHT button ( 56) /
(stop) button ( 39)
Multi selector ( 11) /
EXP button ( 53) /
FOCUS button ( 54) (record review) button ( 34) /
(flash) button ( 57) /
(fast reverse) button ( 40) /
Index screen – button ( 39)
BATT. (battery release) button ( 21)
Serial number
Flash ( 57)
DRIVE MODE button ( 67) /
(fast forward) button ( 40) /
Index screen + button ( 39)
Disc compartment cover ( 31)
Mini video light ( 56)
Remote sensor ( 25)
Battery attachment unit ( 21) Stereo microphone
RESET button ( 122) DC IN terminal ( 21)
Mode dial ( 46)
