Canon LBP252dw User Manual

Setting Up Connection Using WPS Push Button Mode
0W20-02Y
If your wireless router supports WPS push button mode, you can easily set up a connection with a WPS button.
● How to operate the wireless router may vary on each device. See the instruction manuals for your
networking device for help.
1
Press .
2
Use / to select <Network Settings>, and press .
● If the logon screen appears, enter the correct ID and PIN using the numeric keys, and then press .
Logging on to the Machine(P. 34)
3
Select <Wireless LAN Settings>, and press .
● If the <Do you want to enable the wireless LAN?> message is displayed, select <Yes>, and press .
4
Read the message that is displayed, and press .
5
Select <WPS Push Button Mode>, and press .
6
Select <Yes>, and press .
➠ A PIN code is generated.
7
Press and hold the WPS button on the wireless router.
The button must be pressed within 2 minutes after performing step 6.
● Depending on the networking device, you may need to press and hold the button for 2 seconds or longer.
See the instruction manuals for your networking device for help.
Network
138

Canon LBP252dw Specifications

General

Printer Type	Laser
Connectivity	USB 2.0, Ethernet, Wi-Fi
Duplex Printing	Yes
Monthly Duty Cycle	Up to 50, 000 pages
Recommended Monthly Print Volume	750 to 3, 000 pages
Media Types	Plain paper, Heavy paper, Transparency, Label, Envelope
Memory	512 MB
Operating Systems Compatibility	Windows, Mac OS, Linux
Print Speed	30 ppm
Paper Capacity	250 sheets
Warm-up Time	16 seconds
First Print Out Time	6 seconds
Paper Input	250-sheet cassette
Paper Output	100 sheets
Media Sizes	A4, A5, B5, Legal, Letter, Executive, Envelope
Media Weights	60 to 163 g/m²
Interface Type	USB, Ethernet, Wireless
Control Panel	5 Line LCD
Dimensions	400 x 377 x 298 mm
Print Margins	5 mm-top, bottom, left and right
