Canon LBP252dw User Manual

Starting Remote UI
0W20-04Y
To operate remotely, you need to input the IP address of the machine into a Web browser and start the Remote UI.
Check the IP address set to the machine in advance ( Viewing Network Settings(P. 161) ). If you have any
questions, ask your Network Administrator.
1
Start the Web browser.
2
Enter "http://(the IP address of the machine)/" in the address eld, and press the
[ENTER] key.
● If you want to use an IPv6 address, enclose the IPv6 address with brackets (example: http://
[fe80::2e9e:fcff:fe4e:dbce]/).
If a security alert is displayed
● A security alert may be displayed when the Remote UI communication is encrypted (
Enabling SSL
Encrypted Communication for the Remote UI(P. 235) ). When certicate settings or SSL settings have no
errors, continue browsing the Web site.
3
Log on to the Remote UI.
When the Department ID Management is disabled
Select [System Manager Mode] or [General User Mode].
[System Manager Mode]
You can perform all the Remote UI operations and settings. Enter the appropriate ID in [System Manager
ID] and PIN in [System Manager PIN] (
Setting the System Manager ID(P. 207) ). If [System Manager
ID] is not set, you do not need to input anything.
[General User Mode]
Using Remote UI
270

Canon LBP252dw Specifications

General

Printer Type	Laser
Connectivity	USB 2.0, Ethernet, Wi-Fi
Duplex Printing	Yes
Monthly Duty Cycle	Up to 50, 000 pages
Recommended Monthly Print Volume	750 to 3, 000 pages
Media Types	Plain paper, Heavy paper, Transparency, Label, Envelope
Memory	512 MB
Operating Systems Compatibility	Windows, Mac OS, Linux
Print Speed	30 ppm
Paper Capacity	250 sheets
Warm-up Time	16 seconds
First Print Out Time	6 seconds
Paper Input	250-sheet cassette
Paper Output	100 sheets
Media Sizes	A4, A5, B5, Legal, Letter, Executive, Envelope
Media Weights	60 to 163 g/m²
Interface Type	USB, Ethernet, Wireless
Control Panel	5 Line LCD
Dimensions	400 x 377 x 298 mm
Print Margins	5 mm-top, bottom, left and right
