Canon LBP252dw User Manual

Setting IPv4 Address
0W20-035
The machine's IPv4 address can be either assigned automatically by a dynamic IP
addressing protocol, such as DHCP, or entered manually. When connecting the
machine to a wired LAN, make sure that the connectors of the LAN cable are rmly
inserted into the ports ( Connecting to a Wired LAN(P. 135) ). You can test the
network connection if necessary.
Setting IPv4 Address(P. 154)
Testing the Network Connection(P. 156)
Setting IPv4 Address
1
Press .
2
Use / to select <Network Settings>, and press .
● If the logon screen appears, enter the correct ID and PIN using the numeric keys, and then press .
Logging on to the Machine(P. 34)
3
Select <TCP/IP Settings> <IPv4 Settings> <IP Address Settings>.
4
Congure IP address settings.
<Auto Acquire>
Select to automatically assign an IP address via DHCP protocol. When <Auto Acquire: On> is displayed,
automatic addressing is enabled.
<Manually Acquire>
Select to congure the IP address settings by manually entering an IP address. In order to select this
option, <Auto Acquire> must be set to <Off>.
<Check Settings>
Select when you want to view the current IP address settings.
Automatically assigning an IP address
1
Select <Auto Acquire> <Select Protocol>.
Network
154

Canon LBP252dw Specifications

General

Printer Type	Laser
Connectivity	USB 2.0, Ethernet, Wi-Fi
Duplex Printing	Yes
Monthly Duty Cycle	Up to 50, 000 pages
Recommended Monthly Print Volume	750 to 3, 000 pages
Media Types	Plain paper, Heavy paper, Transparency, Label, Envelope
Memory	512 MB
Operating Systems Compatibility	Windows, Mac OS, Linux
Print Speed	30 ppm
Paper Capacity	250 sheets
Warm-up Time	16 seconds
First Print Out Time	6 seconds
Paper Input	250-sheet cassette
Paper Output	100 sheets
Media Sizes	A4, A5, B5, Legal, Letter, Executive, Envelope
Media Weights	60 to 163 g/m²
Interface Type	USB, Ethernet, Wireless
Control Panel	5 Line LCD
Dimensions	400 x 377 x 298 mm
Print Margins	5 mm-top, bottom, left and right
