Conguring IEEE 802.1X Authentication
0W20-04L
The machine can connect to an 802.1X network as a client device. A typical 802.1X network consists of a RADIUS server
(authentication server), LAN switch (authenticator), and client devices with authentication software (supplicants). If a
device tries to connect to the 802.1X network, the device must go through user authentication in order to prove that
the connection is made by an authorized user. Authentication information is sent to and checked by a RADIUS server,
which permits or rejects communication to the network depending on the authentication result. If authentication fails,
a LAN switch (or an access point) blocks access from the outside of the network.
Select the authentication method from the options below. If necessary, install or register a key pair or CA certicate
before conguring IEEE 802.1X authentication ( Using CA-issued Key Pairs and Digital Certicates(P. 262) ).
TLS
The machine and the authentication server authenticate each other by mutually verifying their certicates. A
key pair issued by a certication authority (CA) is required for the client authentication (when authenticating the
machine). For the server authentication, a CA certicate installed via the Remote UI can be used in addition to a
CA certicate preinstalled in the machine. The TLS method cannot be used with TTLS or PEAP at the same time.
TTLS
This authentication method uses a user name and password for the client authentication and a CA certicate for
the server authentication. MSCHAPv2 or PAP can be selected as the internal protocol. TTLS can be used with
PEAP at the same time. Enable SSL for the Remote UI before conguring this authentication method (
Enabling SSL Encrypted Communication for the Remote UI(P. 235) ).
PEAP
The required settings are almost the same as those of TTLS. MS-CHAPv2 is used as the internal protocol. Enable
SSL for the Remote UI before conguring this authentication method ( Enabling SSL Encrypted
Communication for the Remote UI(P. 235) ).
1
Start the Remote UI and log on in System Manager Mode. Starting Remote
UI(P. 270)
2
Click [Settings/Registration].
Security
248

Canon LBP252dw Specifications

General

Printer Type	Laser
Connectivity	USB 2.0, Ethernet, Wi-Fi
Duplex Printing	Yes
Monthly Duty Cycle	Up to 50, 000 pages
Recommended Monthly Print Volume	750 to 3, 000 pages
Media Types	Plain paper, Heavy paper, Transparency, Label, Envelope
Memory	512 MB
Operating Systems Compatibility	Windows, Mac OS, Linux
Print Speed	30 ppm
Paper Capacity	250 sheets
Warm-up Time	16 seconds
First Print Out Time	6 seconds
Paper Input	250-sheet cassette
Paper Output	100 sheets
Media Sizes	A4, A5, B5, Legal, Letter, Executive, Envelope
Media Weights	60 to 163 g/m²
Interface Type	USB, Ethernet, Wireless
Control Panel	5 Line LCD
Dimensions	400 x 377 x 298 mm
Print Margins	5 mm-top, bottom, left and right
