Aligning the Print Head Manually
Try aligning the print head manually after automatic print head alignment if printing results are not as
expected, as when printed ruled lines are misaligned.
You need to prepare: two sheets of A4 or Letter-sized plain paper
1. Check that printer is turned on.1.
2.
Load two sheets of A4 or Letter-sized plain paper in cassette.
2.
Loading Plain Paper in Cassette
3.
Select (Setup) on HOME screen.
3.
Using Touch Screen
The setup menu screen will appear.
4. Select Maintenance.4.
The Maintenance screen will appear.
5.
Select Print Head Alignment - Manual.
5.
The confirmation screen will appear.
Note
•
To print and check the current head position alignment values, select Print the Head Alignment
•
Value.
6.
Check message and select Yes.
6.
The print head alignment pattern will be printed.
7.
When Did the patterns print correctly? appears, make sure pattern was printed correctly,
7.
and if so, select Yes.
139
To Next Page
