159
Appendix
8
Messages Displayed in the Information Field
Messages displayed in the information field of the viewer are classified into the following three types.
Information Messages
List of Viewer Messages
Icon Category Explanation
Information Message Help messages on various buttons, pull-down lists, etc., as well as frame rate and other
information from the camera are shown.
Warning Message A message will be displayed notifying the user when camera control privileges cannot
be obtained, the audio session stops, etc.
Error Message Displayed when a system error occurs in the viewer.
Message Explanation
Connection closed by the camera. The camera was disconnected.
Audio connection has been closed. The video session has continued after the audio session was disconnected
(applicable to both transmission and reception).
Camera control gained. Displayed when camera control is obtained. You can operate the camera.
Camera control lost. Displayed when camera control is released.
You cannot operate the camera
until you get camera control privileges again.
Use the menu displayed by right-clicking to exit the full
screen mode.
When switched to full screen mode
Recording to SD card aborted. When recording to SD card was completed successfully
The connection was terminated because the image has
been flipped.
When the image was flipped during camera connection (camera connection
is terminated when an image is flipped)
The connection was terminated because the password
has been changed.
When the password of the account used to connect to the camera was
changed during camera connection and then any WV-HTTP command was
issued
Message Explanation
{n}fps Pan : {p} Tilt : {t} Zoom : {z} IS: {Image Stabilizer
value}
Communicating with the camera normally
Message Explanation
{n}fps Pan : {p} Tilt : {t} Zoom : {z} Communicating with the camera normally (when Digital PTZ is enabled)
{n}fps Communicating with the camera normally (when Digital PTZ is disabled)
