Canon VB-H41 User Manual

5
User Manuals
This camera comes with an “Installation Guide” and
“Operation Guide” (this manual) included in the Setup
CD-ROM.
In the Setup CD-ROM, the recording software RM-Lite
(“RM-Lite” in “Chapter1 Before Use”) is also included. The
following user manuals are available.
How to use this Operation Guide
The assumed reading format of this user manual is on a
PC screen.
Software Screenshots
The software screenshots shown in these user manuals
are illustrative samples only. The screenshots may differ
from the actual screens displayed.
Screenshots used with the explanations are generally
from a Windows 7 PC connected to the VB-H41.
Icons Indicating Particular Camera
Models
In the descriptions of functions limited to particular
models, the model names will appear or the following
icons will be used to indicate those models.
Symbols Indicating Safety Precautions
This section explains symbols used in this Operation
Guide. This Operation Guide uses the following symbols
to indicate important information the user should know in
order to use the product safely. Be sure to observe these
items.
How to Read This Operation Guide
Installation Guide (Included)
This guide provides notes and procedures on camera
installation as well as the main camera specifications.
Sections you should reference in this guide will be
marked “Installation Guide” along with the name of the
reference items.
Operation Guide (This Document)
(VBH467OG_E.pdf)
This document explains the initial camera settings,
Camera Angle Setting Tool, Admin Tools settings, viewer
operations and troubleshooting, etc. This document is
included in the Setup CD-ROM.
Network Video Recording Software RM-Lite
Administrator Manual (RM20AM_E.pdf)
This document gives a detailed explanation of how to
use RM-Lite.
Network Video Recording Software RM-Lite Viewer
Operation Guide (RM20VOG_E.pdf)
This is the operation guide for RM-Lite Viewer. For more
details on operating procedures for the viewer, see the
Administrator Manual.
Icon Camera Model
VB-H41
VB-H610VE and VB-H610D
VB-H710F
Symbol Meaning
Warning
Inappropriate handling against the
instruction accompanied by this sign
may result in death or serious injury. Be
sure to observe these warnings to
ensure safety.
Caution
Inappropriate handling against the
instruction accompanied by this sign
may result in injury. Be sure to observe
these precautions to ensure safety.
Caution
Inappropriate handling against the
instruction accompanied by this sign
may result in property damage. Be sure
to observe these precautions.
Important
This symbol indicates other actions or
information that should be heeded.
Important notes and restrictions are
provided. Be sure to read this section.
Note
Contains reference information for
operation or additional explanations.

Canon VB-H41 Specifications

Image Sensor

sensor type	1/3 inch CMOS
number of pixels	Approx. 2.1 million pixels
scanning system	Progressive

Optics

zoom magnification and control	20x powered zoom lens with auto focus (12x digital zoom, total 240x zoom)
focal length	4.7mm (wide) – 94mm (telephoto)
horizontal field of view	60.4° (wide) – 3.2° (telephoto)
lens F-number	F1.6 – F3.5
minimum subject illumination (day mode)	0.4 lux (Colour, F1.6 at 1/30 sec, SSC off, 50IRE)
minimum subject illumination (night mode)	0.02 lux (Mono, F1.6 at 1/30 sec, SSC off, 50IRE)
focus control	Auto / One-shot AF / Manual / Fixed at infinity
focusing region (day mode)	0.3 m – infinity (wide) / 1.0 m – infinity (telephoto)
focusing region (night mode)	1.0 m – infinity (wide) / 1.5 m – infinity (telephoto)
shutter speed	1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000 and 1/16000sec

Video and Audio

video compression method	H.264, JPEG
video output size (JPEG)	1920 x 1080, 960 x 540, 480 x 270, 320 x 240
video output size (H.264)	1920 x 1080, 960 x 540, 480 x 270
frame rate (JPEG)	30 – 0.1 fps
frame rate (H.264)	30/15/10/6/5/3/2/1 fps
audio communication	Full-duplex
audio compression method	G.711 μ-law (64 kbps)

Power

power sources	Power over Ethernet (48V DC, Conforms to IEEE 802.3af), 100V – 240V AC, 50/60Hz (via optional AC Adaptor PA-V17), 12V DC or 24V AC (via supplied two-pin connector)
power consumption (PoE)	Max. approx. 9.0 W
power consumption (AC adapter PA-V17)	Max. approx. 10.6 W
power consumption (DC Input)	Max. approx 8.6 W
power consumption (AC Input)	Max. approx. 8.8 W

Operating Environment

operating temperature	-10°C to 50°C
operating humidity	5% – 85% RH (without condensation)

Dimensions and Weight

dimensions (W x H x D)	132mm x 155mm x 132mm
weight	Approx. 1140 g
