Appendix
8
List of Factory Default Settings
Item Setting
• User Name (Administrator ID) root
• Administrator password camera
• Path to setting pages admin
•LAN
LAN Interface Auto
Maximum Packet Size 1500
•IPv4
IPv4 Address Setting Method Manual
IPv4 Address 192.168.100.1
Subnet Mask 255.255.255.0
IPv4 Default Gateway Address
AutoIP Enable
IPv4 Address (AutoIP)
•IPv6
IPv6 Enable
Auto (RA) Enable
Auto (DHCPv6) Enable
IPv6 Address (Manual)
Prefix Length 64
IPv6 Default Gateway Address
IPv6 Address (Auto)
• DNS
Name Server Address 1
Name Server Address 2
Auto-Setting of Name Server
Address
Disable
Host Name
Host Name Registration with
DDNS
Disable
Search Domain
Search Domain List
•SNMP
SNMP Disable
Community Name public
Administrator Contact
Information
Administration Function
Name
VB-H41
VB-H610
VB-H710
Installation Location
• Current Date and Time
• Setting
Setting Method Set manually
Auto-Setting of NTP Server Disable
NTP Server
Time Zone (GMT+09:00) Osaka,
Sapporo, Tokyo
Daylight Saving Time Disable
• Camera Name
Camera Name (alphanumeric
characters)
Camera
• Initial Camera Settings
AE Mode Auto
Slow Shutter Disable
Shutter Speed 1/100
Exposure Compensation 0
Metering Mode Center-Weighted
Focus Mode Auto
Smart Shade Control Disable
White Balance Auto
R Gain 255
B Gain 255
• Camera Control
Digital Zoom Disable
Image Stabilizer Disable
AGC Limit 5
• Day/Night
Mode Manual
Switching Brightness Standard
Response (sec.) 20
• Installation Conditions
Dome Do not use
LED Setting Turn On
Image Flip Disable
• Camera Position Control
Restricted to Presets No Restriction
Camera Position without Control Do not return to Home
Position
Item Setting

Canon VB-H41 Specifications

Image Sensor

sensor type	1/3 inch CMOS
number of pixels	Approx. 2.1 million pixels
scanning system	Progressive

Optics

zoom magnification and control	20x powered zoom lens with auto focus (12x digital zoom, total 240x zoom)
focal length	4.7mm (wide) – 94mm (telephoto)
horizontal field of view	60.4° (wide) – 3.2° (telephoto)
lens F-number	F1.6 – F3.5
minimum subject illumination (day mode)	0.4 lux (Colour, F1.6 at 1/30 sec, SSC off, 50IRE)
minimum subject illumination (night mode)	0.02 lux (Mono, F1.6 at 1/30 sec, SSC off, 50IRE)
focus control	Auto / One-shot AF / Manual / Fixed at infinity
focusing region (day mode)	0.3 m – infinity (wide) / 1.0 m – infinity (telephoto)
focusing region (night mode)	1.0 m – infinity (wide) / 1.5 m – infinity (telephoto)
shutter speed	1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000 and 1/16000sec

Video and Audio

video compression method	H.264, JPEG
video output size (JPEG)	1920 x 1080, 960 x 540, 480 x 270, 320 x 240
video output size (H.264)	1920 x 1080, 960 x 540, 480 x 270
frame rate (JPEG)	30 – 0.1 fps
frame rate (H.264)	30/15/10/6/5/3/2/1 fps
audio communication	Full-duplex
audio compression method	G.711 μ-law (64 kbps)

Power

power sources	Power over Ethernet (48V DC, Conforms to IEEE 802.3af), 100V – 240V AC, 50/60Hz (via optional AC Adaptor PA-V17), 12V DC or 24V AC (via supplied two-pin connector)
power consumption (PoE)	Max. approx. 9.0 W
power consumption (AC adapter PA-V17)	Max. approx. 10.6 W
power consumption (DC Input)	Max. approx 8.6 W
power consumption (AC Input)	Max. approx. 8.8 W

Operating Environment

operating temperature	-10°C to 50°C
operating humidity	5% – 85% RH (without condensation)

Dimensions and Weight

dimensions (W x H x D)	132mm x 155mm x 132mm
weight	Approx. 1140 g
