53
The MONITOR OUT terminal of the projector outputs the video signal being input via the COMPUTER
IN 1 terminal or COMPUTER IN 2 terminal as-is. This makes it possible to simultaneously output the
projection image to another display.
The signals output from the MONITOR OUT terminal when the projector is turned on depends
on the selected input source as shown in the table below.
The projector can be configured to output, from the MONITOR OUT terminal, the video signal
input from the COMPUTER IN 1 terminal while the projector is in the standby state. For details,
see “Option Settings 2 3 Standby RGB/Audio” (page 36).
Using the MONITOR OUT Terminal
When this input source is selected:
The video input signal from this terminal is output to the
MONITOR OUT terminal:
Computer 1 COMPUTER IN 1
Computer 2 COMPUTER IN 2
Video, S-Video, HDMI1, HDMI2,
File Viewer, CASIO USB Tool, Network
The video input signal is output from either Computer 1 or
Computer 2, in accordance with the last selected input source
(COMPUTER IN 1 terminal or COMPUTER IN 2 terminal).*
1
*1 For example, even if the input source is switched from Computer 1 to S-Video, the
MONITOR OUT terminal continues output the video input signal from COMPUTER IN 1.
