35-79
Catalyst 3750 Switch Software Configuration Guide
OL-8550-02
Chapter 35 Configuring IP Unicast Routing
Configuring Protocol-Independent Features
Use the no ip default-network network number global configuration command to remove the route.
When default information is passed through a dynamic routing protocol, no further configuration is
required. The system periodically scans its routing table to choose the optimal default network as its
default route. In IGRP networks, there might be several candidate networks for the system default. Cisco
routers use administrative distance and metric information to set the default route or the gateway of last
resort.
If dynamic default information is not being passed to the system, candidates for the default route are
specified with the ip default-network global configuration command. If this network appears in the
routing table from any source, it is flagged as a possible choice for the default route. If the router has no
interface on the default network, but does have a path to it, the network is considered as a possible
candidate, and the gateway to the best default path becomes the gateway of last resort.
Using Route Maps to Redistribute Routing Information
The switch can run multiple routing protocols simultaneously, and it can redistribute information from
one routing protocol to another. Redistributing information from one routing protocol to another applies
to all supported IP-based routing protocols.
You can also conditionally control the redistribution of routes between routing domains by defining
enhanced packet filters or route maps between the two domains. The match and set route-map
configuration commands define the condition portion of a route map. The match command specifies that
a criterion must be matched; the set command specifies an action to be taken if the routing update meets
the conditions defined by the match command. Although redistribution is a protocol-independent
feature, some of the match and set route-map configuration commands are specific to a particular
protocol.
One or more match commands and one or more set commands follow a route-map command. If there
are no match commands, everything matches. If there are no set commands, nothing is done, other than
the match. Therefore, you need at least one match or set command.
You can also identify route-map statements as permit or deny. If the statement is marked as a deny, the
packets meeting the match criteria are sent back through the normal forwarding channels
(destination-based routing). If the statement is marked as permit, set clauses are applied to packets
meeting the match criteria. Packets that do not meet the match criteria are forwarded through the normal
routing channel.
Note Although each of Steps 3 through 14 in the following section is optional, you must enter at least one
match route-map configuration command and one set route-map configuration command.
Step 4
show ip route Display the selected default route in the gateway of last resort
display.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
