Phone Connections
For your phone to work, it must be connected to the corporate IP telephony network.
Figure 3: Cisco IP Phone 6961 connections
Access port (10/100 PC) connection.5DC adaptor port (DC48V).1
Handset connection.6AC-to-DC power supply (optional).2
Headset connection (optional).7AC power wall plug (optional).3
Network port (10/100 SW) connection. IEEE
802.3af power enabled.
4
Cisco Unified IP Phone 6921, 6941, 6945, and 6961 User Guide for Cisco Unified Communications Manager 9.0 (SCCP
and SIP)
19
