Cisco 7961G Administration Guide

7-5
Cisco IP Phone Administration Guide for Cisco CallManager, Cisco IP Phone 7961G/7961G-GE and 7941G/7941G-GE
OL-6966-01
Chapter 7 Viewing Security Information, Model Information, Status, and Statistics on the Cisco IP Phone
Model Information Screen
• SRST Router— IP address of the trusted SRST router that is available to the
phone, if such a device has been configured in Cisco CallManager
Administration. Also displays a certificate icon if a certificate is
installed for this server.
Model Information Screen
The Model Information screen shows the following information:
• Model Number—Model number of the phone.
• MAC Address—MAC address of the phone.
• Load File—Identifier of the factory-installed load running on the phone.
• Boot Load ID—Identifier of the factory-installed load running on the phone.
• Serial Number—Serial number of the phone.
• CTL File—Displays the MD5 hash of the certificate trust list (CTL) file that
is installed in the phone. If no CTL file is installed on the phone, this field
displays No. (If security is configured for the phone, the CTL file installs
automatically when the phone reboots or resets. For more information about
this file, refer to the Cisco CallManager Security Guide.)
• MIC—Indicates whether a manufacturing installed certificate (used for the
security features) is installed on the phone or is not installed on the phone.
• LSC—Indicates whether a locally significant certificate (used for the security
features) is installed on the phone or is not installed on the phone.
• Call Control Protocol—Indicates the call processing protocol used by the
phone.
To display the Model Information screen, press the Settings button and then
select Model Information.
To exit the Model Information screen, press the Exit softkey.
