Cisco 7961G Administration Guide

7-15
Cisco IP Phone Administration Guide for Cisco CallManager, Cisco IP Phone 7961G/7961G-GE and 7941G/7941G-GE
OL-6966-01
Chapter 7 Viewing Security Information, Model Information, Status, and Statistics on the Cisco IP Phone
Status Menu
Firmware Versions Screen
The Firmware Versions screen displays information about the firmware running
on the phone. Table 7-3 describes the information that appears in this screen.
To display the Firmware Version screen, press the Settings button, and then
choose Status > Firmware Versions.
To exit the Firmware Version screen, press the Exit softkey.
Expansion Module Status Screen
The Expansion Module Status screen displays information about the
Cisco IP Phone 7914 Expansion Module or modules, if connected to the phone.
Table Table 7-4 explains the information that appears in this screen for each
connected expansion module. You can use this information to troubleshoot the
expansion module, if necessary. In the Expansion Module Stats screen, a statistic
preceded by “A” is for the first expansion module. A statistic preceded by “B” is
for the second expansion module.
To display the Expansion Module Stats screen, press the Settings button, and then
choose Status > Expansion Module.
To exit the Expansion Module Status screen, press the Exit softkey.
Table 7-3 Firmware Version Information
Item Description
Load File Load file running on the phone
App Load ID Identifies the JAR file running on the phone
JVM Load ID Identifies the Java Virtual Machine (JVM) running
on the phone
OS Load ID Identifies the operating system running on the phone
Boot Load ID Identifies the factory-installed load running on the
phone
Expansion Module 1
Expansion Module 2
Identifies the load running on the Expansion
Module(s), if connected to the phone.
