Cisco SG200 Series User Manual

Port Management
Configuring PoE
Cisco Small Business SG200 Series 8-port Smart Switch 97
4
• Power Management Mode—Select how the switch prioritizes the power
that it provides to multiple ports:
- Static with Port Priority—Static with priority power management. This
algorithm pre-allocates power based on the configured power limit and
the priority of the port.
- Dynamic with Port Priority—Dynamic with priority power
management. This algorithm supplies power to devices as long as the
consumption is within the configured limit and priority. There is no pre-
allocation of power.
In both modes, a port with a higher port priority is given preference when the
switch supplies power to multiple ports. If two or more port priorities are
equal, the port with the lower port number is given preference.
• Reset Mode—Select Enable to enable the switch initialize all PoE ports state
machines.
STEP 3 Click Apply. Your changes are saved to the Running Configuration.
NOTE This page displays the following data for PoE power on the switch:
• Power: The current power status. If On, the switch is currently providing
power through PoE to a connected device. If Off, the switch is not providing
power through PoE to any connected devices.
• Maximum Available Power—The total power in watts that the switch is
capable of making available to all PoE-capable ports.
• Threshold Power—The cutoff power value above which no additional PDs
are powered. This threshold is calculated based on the Power Trap
Threshold setting.
• Allocated Power—The total power in watts that the switch is actually
providing to PoE ports.
