D-Link DAP-1150 User Manual

DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Router Mode)
Status
The pages of this section display data on the current state of the access point switched to the router
mode:
• network statistics
• the routing table
• data on devices connected to the device's network and its web-based interface.
Network Statistics
On the Status / Network statistics page, you can view statistics for all interfaces (connections)
existing in the system. For each connection the following data are displayed: state, IP address,
subnet mask and gateway (if the connection is established), MAC address, MTU value, and volume
of data received and transmitted (with increase of the volume the units of measurement are changed
automatically: byte, Kbyte, Mbyte, Gbyte).
Figure 93. The Status / Network statistics page.
Page 100 of 175

D-Link DAP-1150 Specifications

General

Frequency band	2.4 GHz
Ethernet LAN data rates	100 Mbit/s
Maximum data transfer rate	54 Mbit/s
Connectivity LEDs	WLAN, LAN, WPS
Wireless technology	802.11g/b
Antenna gain level (max)	2 dBi
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, AES, EAP-SIM, PEAP, SSL/TLS, TKIP, TTLS, WPA-EAP, WPA-PSK, WPA2-EAP, WPA2-PSK
Operating temperature (T-T)	0 - 55 °C
Certification	FCC Class B, CE, C-Tick, Wi-Fi
Power requirements	5VDC 1.2A

Weight and Dimensions

Weight	220 g
Dimensions (WxDxH)	144 x 109 x 30 mm
