D-Link DAP-1150 User Manual

DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Overview
Back Panel
Figure 2. Back panel view.
Port Description
LAN
Access point mode: an Ethernet port to connect to a computer.
Router mode: an Ethernet port to connect to a cable or DSL modem
or to a private Ethernet line (it is recommended to use the cable
included in the delivery package).
5V=1.2A Power connector.
RESET
A button to restore the factory default settings.
Power off the device. Push the RESET button. Power on the device
keeping the RESET button pushed, and after 5 seconds release the
button.
The device is equipped with a detachable antenna (Reverse SMA).
Page 11 of 175

D-Link DAP-1150 Specifications

General

Frequency band	2.4 GHz
Ethernet LAN data rates	100 Mbit/s
Maximum data transfer rate	54 Mbit/s
Connectivity LEDs	WLAN, LAN, WPS
Wireless technology	802.11g/b
Antenna gain level (max)	2 dBi
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, AES, EAP-SIM, PEAP, SSL/TLS, TKIP, TTLS, WPA-EAP, WPA-PSK, WPA2-EAP, WPA2-PSK
Operating temperature (T-T)	0 - 55 °C
Certification	FCC Class B, CE, C-Tick, Wi-Fi
Power requirements	5VDC 1.2A

Weight and Dimensions

Weight	220 g
Dimensions (WxDxH)	144 x 109 x 30 mm
