D-Link DAP-1150 User Manual

DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Router Mode)
You can specify the following parameters:
Parameter Description
DDNS Service Select a DDNS provider from the drop-down list.
Host name
The domain name registered at your DDNS provider.
User name The username to authorize for your DDNS provider.
User password
The password to authorize for your DDNS provider.
Interface
Select a WAN connection which IP address will be used to access
the DDNS service.
Update period
An interval (in minutes) between sending data with the IP address of
the interface specified in the field above to the relevant DDNS
service.
Click the Change button.
To edit parameters of the existing DDNS service, click the relevant service link. On the opened
page, change the needed parameters and click the Change button.
To remove an existing DDNS service, click the relevant service link. On the opened page, click the
Delete button.
Page 149 of 175

D-Link DAP-1150 Specifications

General

Frequency band	2.4 GHz
Ethernet LAN data rates	100 Mbit/s
Maximum data transfer rate	54 Mbit/s
Connectivity LEDs	WLAN, LAN, WPS
Wireless technology	802.11g/b
Antenna gain level (max)	2 dBi
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, AES, EAP-SIM, PEAP, SSL/TLS, TKIP, TTLS, WPA-EAP, WPA-PSK, WPA2-EAP, WPA2-PSK
Operating temperature (T-T)	0 - 55 °C
Certification	FCC Class B, CE, C-Tick, Wi-Fi
Power requirements	5VDC 1.2A

Weight and Dimensions

Weight	220 g
Dimensions (WxDxH)	144 x 109 x 30 mm
