Configuring Device (Router Mode)
Figure 136. The page for adding a rule for remote management.
You can specify the following parameters:
Parameter Description
IP address
A host or a subnet to which the rule is applied.
Mask The mask of the subnet.
Protocol
The protocol available for remote management of the access point.
Public port An external port of the access point. You can specify only one port.
Click the Change button.
To edit a rule for remote access, click the relevant link. On the opened page, change the needed
parameters and click the Change button.
To remove a rule for remote access, click the relevant link. On the opened page, click the Delete
button.
Page 155 of 175

D-Link DAP-1150 Specifications

General

Frequency band	2.4 GHz
Ethernet LAN data rates	100 Mbit/s
Maximum data transfer rate	54 Mbit/s
Connectivity LEDs	WLAN, LAN, WPS
Wireless technology	802.11g/b
Antenna gain level (max)	2 dBi
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, AES, EAP-SIM, PEAP, SSL/TLS, TKIP, TTLS, WPA-EAP, WPA-PSK, WPA2-EAP, WPA2-PSK
Operating temperature (T-T)	0 - 55 °C
Certification	FCC Class B, CE, C-Tick, Wi-Fi
Power requirements	5VDC 1.2A

Weight and Dimensions

Weight	220 g
Dimensions (WxDxH)	144 x 109 x 30 mm
