DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Router Mode)
You can specify the following parameters:
Parameter Description
Template
Select a virtual server template from the drop-down list, or select
Custom to specify all parameters of the new virtual server
manually.
Name
A name for the virtual server for easier identification. You can
specify any name.
Interface
A WAN connection to which this virtual server will be assigned.
Protocol
A protocol that will be used by the new virtual server. Select a value
from the drop-down list.
Public port (begin)/
Public port (end)
A port of the access point from which traffic is directed to the IP
address specified in the Private IP field. Specify the start and the
end value for the port range. If you need to specify one port, enter
the needed value in the Public port (begin) field and leave the
Public port (end) field blank.
Private port (begin)/
Private port (end)
A port of the IP address specified in the Private IP field to which
traffic is directed from the Public port. Specify the start and the
end value for the port range. If you need to specify one port, enter
the needed value in the Private port (begin) field and leave the
Private port (end) field blank.
Private IP
The IP address of the server from the local area network. To choose
a device connected to the access point's LAN at the moment, select
the relevant value from the drop-down list located to the right of the
Private IP field (the field will be filled in automatically).
Remote IP The IP address of the server from the external network.
Click the Change button.
To edit the parameters of an existing server, follow the link with the name of the server. On the
opened page, change the needed parameters and click the Change button.
To remove an existing server, follow the link with the name of the server. On the opened page, click
the Delete button.
Page 161 of 175
