DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Access Point Mode)
To activate the WPS function, select the WPS Enable checkbox and click the Change button.
When the checkbox is selected, the Information and Connection sections are available on the
page.
Parameter Description
Default PIN code
The PIN code of the access point. This parameter is used when
connecting the access point to a registrar to set the parameters of the
WPS function.
WPS Status
The state of the WPS function:
• Configured (all needed settings are specified)
• Unconfigured (you need to specify the relevant settings).
SSID
The name of the device's WLAN (or the first part of the WLAN if
the network is splitted into parts).
Network Authentication
The network authentication type specified for the WLAN (or first
part of the WLAN).
Encryption
The encryption type specified for the WLAN (or the first part of the
WLAN).
Encryption key
The encryption key specified for the WLAN (or the first part of the
WLAN).
Refresh
Click the button to view the latest data on the state of connecting the
wireless device via the WPS function.
Reset to unconfigured Click the button to reset the parameters of the WPS function.
WPS Method
A method of the WPS function. Select a value from the drop-down
list.
PIN: Connecting the device via the PIN code.
PBC: Connecting the device via the push button (actual or virtual).
PIN Code
The PIN code of the WPS-enabled device that needs to be connected
to the wireless network of the access point.
The field is displayed only when the PIN value is selected from the
WPS Method drop-down list.
Connect
Click the button to connect the wireless device to the WLAN of the
access point via the WPS function.
Page 52 of 175
