DIR-815 AC1200 Wave 2 MU-MIMO Wi-Fi

Router with 3G/LTE Support and USB Port

User Manual

Configuring via Web-based Interface

Creating 3G WAN Connection

If the PIN code check is enabled for the SIM card inserted into your USB modem, then prior to

creating a 3G WAN connection, go to the USB Modem menu and enter the PIN code

on the page

displayed (see the USB Modem section, page 168). Then on the connection creation page, in the

General Settings section, select the relevant value from the Connection type drop-down list

and specify the needed values.

Figure 83. The page for creating a new 3G connection. The General Settings section.

Parameter Description

General Settings

Interface

A physical or virtual WAN interface to which the new connection

will be assigned.

Connection name A name for the connection for easier identification.

Enable connection

Move the switch to the right to enable the connection.

Move the switch to the left to disable the connection.

10 For some models of 3G USB modems it is required to disable the PIN code check on the SIM card prior to

connecting the USB modem to the router.

Page 105 of 240
