Name: D-Link DIR-815
Brand: D-Link
Rating: 5 (1 reviews)

To Next Page

To Previous Page

DIR-815 AC1200 Wave 2 MU-MIMO Wi-Fi

Router with 3G/LTE Support and USB Port

User Manual

Overview

Specifications

Hardware

Processor

· RTL8197FN (1GHz)

RAM

· 64MB, DDR2, built in processor

Flash

· 16MB, SPI

Interfaces

· 10/100BASE-TX WAN port

· 4 10/100BASE-TX LAN ports

· USB 2.0 port

LEDs

· Power

· Internet

· 4 LAN LEDs

· 2.4G WLAN

· 5G WLAN

· WPS

· USB

Buttons

· POWER button to power on/power off

· WiFi button to enable/disable wireless network

· WPS button to set up wireless connection

· RESET button to restore factory default settings

Antenna

· Four external non-detachable antennas (5dBi gain)

MIMO

· 2 x 2, MU-MIMO

Power connector

· Power input connector (DC)

Software

WAN connection types

· LTE (via supported USB modem)

· 3G (via supported USB modem)

· PPPoE

· IPv6 PPPoE

· PPPoE Dual Stack

· Static IPv4 / Dynamic IPv4

· Static IPv6 / Dynamic IPv6

· PPPoE + Static IP (PPPoE Dual Access)

· PPPoE + Dynamic IP (PPPoE Dual Access)

· PPTP/L2TP + Static IP

· PPTP/L2TP + Dynamic IP

* The device features are subject to change without notice. For the latest versions of the firmware and relevant

documentation, visit www.dlink.ru.

Page 8 of 240

Other manuals for D-Link DIR-815

Quick Installation Guide57 pages

Specifications2 pages

Questions and Answers:

Need help?

Do you have a question about the D-Link DIR-815 and is the answer not in the manual?

D-Link DIR-815 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz Channel 1Nss	65/72.2 Mbps (max)
IEEE 802.11n 20MHz Channel 2Nss	130/144.44 Mbps (max)
IEEE 802.11n 40MHz Channel 1Nss	135/150 Mbps (max)
IEEE 802.11n 40MHz Channel 2Nss	270/300 Mbps (max)
IEEE 802.11a	54 Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 9Mbps - 6Mbps
IEEE 802.11g	54Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 11Mbps - 9Mbps - 6Mbps

Wireless Frequency Range
