DIR-815 AC1200 Wave 2 MU-MIMO Wi-Fi

Router with 3G/LTE Support and USB Port

User Manual

Configuring via Web-based Interface

Selecting Operation Mode

Select the needed operation mode and click the NEXT button.

Router

In order to connect your device to a wired ISP, on the Device mode page, from the Connection

method list, select the Wired connection value. Then from the Work mode list select the

Router value. In this mode you can configure a WAN connection, set your own settings for the

wireless network in the 2.4GHz and 5GHz bands, configure LAN ports to connect an STB or VoIP

phone, and set your own password for access to the web-based interface of the device.

Figure 33. Selecting an operation mode. The Router mode.

In order to connect your device to the network of a 3G or LTE operator, on the Device mode

page, from the Connection method list, select the 3G/LTE modem value. In this mode you can

configure a 3G/LTE WAN connection, set your own settings for the wireless network in the 2.4GHz

and 5GHz bands, and set your own password for access to the web-based interface of the device.

Figure 34. Selecting an operation mode. The 3G/LTE modem mode.

Page 49 of 240
