DIR-815 AC1200 Wave 2 MU-MIMO Wi-Fi

Router with 3G/LTE Support and USB Port

User Manual

Configuring via Web-based Interface

IPv6

Go to the IPv6 tab to change IPv6 address of the router and configure IPv6 addresses assignment

settings.

Figure 94. Configuring the local interface. The IPv6 tab. The Local IPv6 Address section.

Parameter Description

Local IPv6 Address

Mode of local IP

address assignment

Select the needed value from the drop-down list.

• Static: An IPv6 address and a prefix are specified manually.

• Prefix delegation: The router requests a prefix to

configure an IPv6 address from a delegating router.

IPv6 address

The IPv6 address of the router in the local subnet with a decimal

value of the prefix length. By default, the following value is

specified: fd01::1/64. The field is available for editing if the

Static value is selected from the Mode of local IPv6 address

assignment drop-down list.

Gateway IPv6 address

Available if the Access point, Repeater, or Client mode was

selected in the Initial Configuration Wizard.

The gateway IPv6 address which is used by the router to connect to

the Internet (e.g., for synchronizing the system time with an NTP

server). Optional.

Hostname

The name of the device assigned to its IP address in the local subnet.

Page 117 of 240
